Typical Applications

    Carton Blanks
    Garden Seed Bags
    Posters and laminates
    Other Large/Wide Bags
    And many more…

Specifications

    Minimum product size: 25mm(W) x 38mm(L) [1" x 1.5"]
    Maximum product size: 900mm(W) [36" Wide]
    Minimum product thickness: 0.05mm [0.002"]
    Maximum product thickness: 27mm [1"]
    Maximum belt speed: 250,000 mm/min [10,000 in/min]
    Operating Temperature 5-40 Degrees C [41-104 Degrees F]
    Power Input: 115VAC or 230VAC 1 ph.
    Product sensor: Infrared emitter / receiver pair for optical reading of product thickness, and for providing feedback if single, multiple, or no product is present.
    Total unit weight: 35 kg [77lb] to 60 kg [132lb] (model dependent)
    Product magazine: 750 mm [30 inches]

Standard Features

    Portable unit: Self-contained unit with only one electrical enclosure
    Computer controlled: Computer control provides thousands of control calculations per second for precise start, stop, watch dog and multiple product detection
    Easy interface: Standard signals available for easy interface with existing computer, PLC or other host machinery
    Production log: Automatically stores your production history in the feeder’s computer with production count, and fault logging with time, date and type of fault
    Intuitive user interface: Custom 22-key sealed membrane key pad with 2 x 40 character LCD display
    User-friendly changeover: Easy and accurate changeover with twist lock handles
    Ruggedly built: Hardened stainless steel shafts and sealed bearings for maximum life and 24-hour a day operation
    Quick belt replacement: Three piece shaft assemblies for quick maintenance
    Three-color signal light: Green = ready, Yellow = low product, Red = fault
    Pre-select counter: Standard pre-select product count (1-999 per cycle)
    Optically isolated signals: All interface signals isolated for accuracy
    Built for harsh environments: Stainless steel shafts, sealed bearings, surface-treated aluminum construction and sealed cast aluminum enclosures to protect internal parts
    One year warranty: One year warranty on parts and labor
    Software Lockout Function Option: Allows user to lock out some or all feeder functions for simplicity for the operator.
    Encoder Speed Match Option: Allows for an input from an encoder connected directly to the feeder to monitor the speed of the host machine. The feeder will monitor the speed of the host machine and adjust its timing accordingly.
    Advanced Error Control: Multiple Product Detection (MPD), Too Thin Product Detection (TTPD), Watch Dog Product Jam Detection (WD-PJD), and Watch Dog No Product Detection (WD-NPD)
    Advanced Help Function: Allows the operator to press the on-board help key at any point of time to get instant help with the feature/function being configured.

Options

    Operator safety guards over feed belts and discharge belts.
    Lockable see-thru guard over keypad.
    Low product alert
    Three or Four color signal light, with or without audible alarm.
    Advanced Warning Control: Monitors the feeding process, the feeders performance, and alerts the operator and/or stamps the production log with messages
    Vacuum track on feed belts
    Variable length discharges
    Flexible discharges with adjustable angles
    Discharge table, with textured top or roller table
    Extended product magazine
    Integrated with Barcode scanners, Inkjet Printers, Labelers, etc.
    Custom engineering, hardware, and software for any application
    Automatic Drop Table
    Automatic Stock Joggers (dual or single)
    High speed Batch Droppers
    Portable stand
    Catch trays
    Remote keypads
    High-speed Collators
    High-speed
    Flat Belt Conveyors
